Precision Wire Stripper ESD-PLUS 001
Conductors, strands and wires from 0.12 to 0.40 mm Ø | AWG 36 - 26
- Area of application: Electronics, telecommunications and model making
- Application area: Conductors, strands and wires from 0.12 to 0.40 mm Ø | AWG 36 - 26
- ESD tested: tool housing made of electrostatically dissipative special plastic
- Adjustment range: 0.12 / 0.16 / 0.20 / 0.25 / 0.30 / 0.40
- Length stop: Continuously adjustable from 1.5 to 22 mm | 0.056 to 0.87 inches
- Side cutters: for wires up to max. 1.0mm diameter | AWG 18
- Suitable for: PVC, TEFLON®, KYNAR®, TEFZEL®, MYLAR®, among others
- Easy to use: Light and compact micro precision stripping tool
Product description
Light and handy micro precision wire stripper for conductors, strands and wires from 0.12 to 0.40 mm Ø | AWG 36 - 26. Tool housing made of electrostatically dissipative material. Ideal for conductors made of PVC, TEFLON®, KYNAR®, TEFZEL®, MYLAR®. Stripping range adjustable in steps of 0.12 / 0.16 / 0.20 / 0.25 / 0.30 / 0.40 mm Ø. Includes adjustable length stop from 1.5 to 22 mm and cutting device for wires up to 1.00 mm Ø. The lever blade is replaceable.
Compatible cables
Cable types listed as compatible by JOKARI. Click one to see tools for that cable.
OEM documentation
- Datasheet Datasheet 1224 KB Download ↓
- Manual User manual 2285 KB Download ↓
